Manitowoc GROVE GMK4090 Maintenance Manual

Spare parts required for maintenance
11.2 Lighting
07.12.2017
Maintenance manual 3 302 649 en 11 - 3
GMK4090
Red triple light strip for USA:
(at the rear of the chassis)
– Triple light strip 7581100056 LED
White front marker lights:
(at the top on the driver's cab)
– Marker light 01207144 R10W 24 V
Outrigger beam spotlights:
(above the front and rear outrigger beams)
– LED spotlight; complete 03143786 M70 LED
Yellow rotating beacon:
(on the driver's cab)
– Rotating beacon; complete 04156048
Inside light:
(in the driver's cab)
– Cab light 03135111 24 V 24 V / 15 W
– Reading light 03135111 24 V 24 V / 15 W
Dashboard light:
(in the driver's cab; socket 12 V)
– Filament lamp 04159964 Xenon 12 V / 6 W
s
Installation point GROVE part
number
Designation Output (W)
