Spare parts required for maintenance
11.3 Spare parts for the carrier
11 - 6 3 302 649 en Maintenance manual
GMK4090
07.12.2017
Wheels
Wheel nuts for steel rims
01207756
In case of damage;
12 each per wheel
Wheel nuts for aluminium rims 7659100000
Vehicle brake (per axle lines)
1. and 2nd axle line (duplex brake):
Brake shoe with brake lining
Spring
Brake drum
only in the case of wear on the
drum brakes
03322112 4
03322110 4
01925703 2
3. and 4th axle line (simplex brake)
Brake shoe with brake lining
Spring
Brake drum
03322121 4
02315393 4
01925703 2
Suspension
Ventilation filter (collecting container)
03324588 1 Only if clogged
Compressed air system
Valve (if defective)
Gasket 22 x 27 Cu DIN 7603
01570750 (8)
00117142 (8)
Filter cartridge 04157844 1
Hydraulic system
Filters 1 and 2 (only clean)
Packing set
03329152 (2)
04163599 (2)
Filters 1 and 2
Packing set
03329152
at every oil change
and when the symbol lights up
2
04163599 2
Filters 3 and 4
Packing set
03140253 2
03135867 2
Oil tank cover gasket 140 / 90 x 3
03328286
1 item for every oil change
(if damaged)
Ventilation filter 01576026 1
Air conditioning system
Driver's cab pollen filter
03254375 1
Other maintenance work
Driver's cab wiper blades
04159795 (2) (if damaged)
Assemblies and spare parts
Carrier
GROVE
Part number
Quantity, in single parts
For maintenance interval
W M 1 M 3 M 6 M 12
