Manitowoc GROVE GMK4090 Maintenance Manual

Lubricants and consumables
6.1 Lubricants
6 - 4 3 302 649 en Maintenance manual
GMK4090
07.12.2017
Con-
sec.
no.
Lubricant
type
Usage Fill
quantity
in litres
(gal)
Mainte-
nance
interval
9
Lubricating
grease
Carrier central lubrication;
à p. 7 - 109 W
Superstructure central lubrication; à p. 8 - 67 W
Cardan shafts – transverse; à p. 7 - 64 M 1
Cardan shafts – longitudinal; à p. 7 - 65 M 6
Towbar coupling; à p. 7 - 125 M 1
Outrigger beams; à p. 7 - 134 M 1
Turntable lock; à p. 8 - 30 M 12
Hook blocks; à p. 8 - 69 M 12
Cab door hinges; à p. 7 - 135 M 12
Carrier pins; à p. 7 - 136 M 12
Superstructure pins; à p. 8 - 83 M 12
10 Spray Slewing bearing gear teeth; à p. 8 - 25 M 6
11 Slide paste Telescopic slide faces; à p. 8 - 46 M 3
12
Lubricating
grease
Telescopic locking pins;
à p. 8 - 46 M 3
Derricking cylinder piston rod; à p. 8 - 45 M 1
Cab door rails; à p. 8 - 81 M 12
Stair tread rails; à p. 8 - 82 M 12
13 Spray
Outrigger pad/supporting cylinder;
à p. 7 - 134
M 1
Derricking cylinder piston rod; à p. 8 - 45 M 1
14
Lubricating
grease
Lubricating the hoist ropes;
à p. 8 - 53 M 3
