Grove Published 7-23-2020, Control # 668-02 3-3
GRT9165 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
OPERATOR CAB OVERVIEW
Most of the controls and indicators, that are used to operate
and monitor crane functions, are found inside the operator
cab (Figure 3-1).
Item Description Page Item Description Page
1 Steering Wheel and Column 3-4 8 Foot Pedal Controls 3-35
2 Right Overhead Control Panel 3-10 9 Internal RCL Light Bar 3-37
3 Left Overhead and Side Panel 3-16 10 3-View Camera Display 3-38
4 Right Lower Control Panel 3-18 11 Front Cab – Controls and Features 3-39
5 Operator Display Module 3-20 12 Rear Cab – Controls and Features 3-41
6 Rated Capacity Limiter Display Module 3-20 13 Right Window and Skylight Window 3-45
7 Operator Seat and Armrest Controls 3-24
FIGURE 3-1
9838-1
2
1
5
6
13
4
8
7
12
3
10
11
9
