Manitowoc Grove GRT9165 User Manual

Grove Published 7-23-2020, Control # 668-02 5-5
GRT9165 OPERATOR MANUAL SET-UP AND INSTALLATION
5
Beacon Lights (Optional)
The optional beacon lights (1, Figure 5-4) can be installed as
part of the optional Auxiliary Lighting and Convenience
Package. When installed, the beacons are located on the
rear of the superstructure. The beacons must be lowered for
transport and raised for operation.
Lowering the Beacon Light for Transport
1. Loosen the wing nut (2). Lower the beacon light (1).
2. Tighten the wing nut (2) to secure the beacon light (1) in
the transport position.
Raising the Beacon Light for Operation
1. Loosen the wing nut (2). Raise the beacon light (1).
2. Tighten the wing nut (2) to secure the beacon light (1) in
the working position.
FIGURE 5-4
1
2
Working Position
Transport Position
1
2
9934
9933
