Grove Published 7-23-2020, Control # 668-02 3-45
GRT9165 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
RIGHT WINDOW AND SKYLIGHT WINDOW
The right window and skylight window (Figure 3-32) can be
opened for ventilation. The skylight sun shade can be
adjusted to multiple positions to allow varying amounts of
light into the cab.
FIGURE 3-32
9838-17
Item Description Page
1 Skylight Window Latch (If Equipped) 3-46
2 Skylight Sun Shade 3-46
3 Right Side Window Latch 3-46
1
3
2
