Grove Published 7-23-2020, Control # 668-02 3-55
GRT9165 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
3
Auxiliary Ladder (Optional)
An auxiliary ladder (1, Figure 3-48) is optional crane
equipment and can be used to access the front or back of the
crane when the outriggers boxes have been removed (refer
to Access Ladders, page 5-8).
The auxiliary ladder is stowed on the right side of the crane
and mounted under the battery box.
FIGURE 3-45
9838-22a
RIGHT SIDE
2
2
1
FIGURE 3-46
9838-22b
FRONT
1
2
2
FIGURE 3-47
9838-22c
REAR
2
2
1
FIGURE 3-48
9838-22a
RIGHT SIDE
1
