GRT9165 OPERATOR MANUAL OPERATING CONTROLS AND FEATURES
3
FOOT PEDAL CONTROLS
The foot pedal controls (Figure 3-26) include the swing brake
pedal, service brake pedal, and throttle pedal.
FIGURE 3-26
Item Description Page
1 Swing Brake Pedal 3-36
2 Service Brake Pedal 3-36
3 Throttle Pedal 3-36
4 Floor Mat 3-36
9838-13
3
21
4
