Grove Published 11-22-2016, Control # 345-12 2-63
RT9130E-2 SERVICE MANUAL HYDRAULIC SYSTEM
2
FIGURE 2-37
Item Description
1 Manifold
2 Solenoid Valve
3 Pressure Reducing Valve
4Check Valves
5 Pressure Switch
6 Gauge Port A
7 Gauge Port B
8017
5
3
4
1
2
5
3
4
1
2
8017-2
6 7
8017-3
