3-20 Published 11-22-2016, Control # 345-12
ELECTRICAL SYSTEM RT9130E-2 SERVICE MANUAL
FIGURE 3-11
Item Description
1
O/R Extend/Retract Switch
2 Fuses 17, 18, 19
3 ACC #2 Relay
4 Rear Steer Switch
5 Tele Cyl Charge Relay #2
6 Tele Cyl Charge Relay #1
7 Rated Capacity Limiter (RCL)
8 Tele Cyl Charge Indicator
9 Tele Cyl Charge Pressure Switch
10 Tele Cyl Pressure Buzzer Relay
11
Power Panel Module
12 Buzzer
13 Crane Buzzer Relay
Item Description
2
1
4
3
6
5
8
7
10
9
11
13
12
