Manitowoc Grove RT9130E-2 Service And Maintenance Manual

Grove Published 11-22-2016, Control # 345-12 7-7
RT9130E-2 SERVICE MANUAL POWER TRAIN
7
6076
1
2
3, 4, 18
5
6
7
8
9
17
FIGURE 7-2
7
16
12
10
18
11
13
13
15
14
Item Description
1 Fuel Quantity Sending Unit
2 Filler Cap
3 Fuel Filter
4 Fuel-Water Separator
5 Fuel Supply
6 Fuel Return
7 Strap Assembly
8Steps
9 Fuel Tank
Item Description
10 Oil Cooler
11 Line To Engine
12 Line To Return Port On Tank
13 Bracket
14 Drain Port
15 Return
16 Supply
17 Vent
18 Water-in-Fuel Sensor
