2-14 Published 11-22-2016, Control # 345-12
HYDRAULIC SYSTEM RT9130E-2 SERVICE MANUAL
Hydraulic Reservoir Removal
1. Drain reservoir. Tag and disconnect lines from the
reservoir. Cover lines and reservoir fittings to prevent
contamination.
2. Secure reservoir with proper lifting device.
3. Remove the capscrews, flatwashers, lockwashers and
nuts securing the reservoir to the frame. Using a suitable
lifting device, remove the reservoir.
4. Clean reservoir and magnetic plug. Service filter
assembly. Then reinstall plug and filter assembly.
Hydraulic Reservoir Installation
1. Using a suitable lifting device, place the reservoir on the
frame. Secure reservoir with the capscrews,
flatwashers, lockwashers and nuts.
2. Attach lines to reservoir.
3. Fill reservoir; verify there is no leakage.
Breather Removal and Replacement
1. Wipe any dirt from the breather.
2. Unscrew the breather from the fill neck.
3. Screw the replacement breather into the fill neck.
DANGER
Ensure that all hydraulic systems are shut down and the
pressure is relieved. Wear eye protection. Hydraulic fluid
can blind or severely damage eyes.
DANGER
Ensure that all hydraulic systems are shut down and the
pressure is relieved. Wear eye protection. Hydraulic fluid
can blind or severely damage eyes.
