Manitowoc Grove RT9130E-2 Service And Maintenance Manual

Grove Published 11-22-2016, Control # 345-12 2-23
RT9130E-2 SERVICE MANUAL HYDRAULIC SYSTEM
2
Main Directional Control Valve
1
2
3
4
5
6
7
8
9
10
Item Description
1
Telescope Inner Mid Extend Port
Relief
2 High Pressure Jam Nut
3 High Pressure Adjustment Nut
4
Telescope Center Outer Mid
Extend 2 Stage Port Relief
5 Low Pressure Adjustment Nut
6 Low Pressure Jam Nut
7 Valve Inlet Section
8 Load Sense Relief
9
Telescope Center/Outer Mid
Retract Port Relief
10
Telescope Inner Mid Retract Port
Relief
11 System Pressure Test Port
12 Load Sense Test Port
FIGURE 2-7
11
12
7128-6
