Manitowoc Grove RT9130E-2 Service And Maintenance Manual

Grove Published 11-22-2016, Control # 345-12 2-45
RT9130E-2 SERVICE MANUAL HYDRAULIC SYSTEM
2
NOTE: R.H. and L.H. controllers oriented from seated operator.
Ports of control lever seen facing aft looking at seat with armrest in up position.
65
4
1
2
3
10
7
8
9
FIGURE 2-25
Swing
Main Hoist
Telescope or
Aux Hoist
Lift
3
4
5, 9
1, 7
4
4
6, 10
2, 8
3
FWD BACK
BACKFWD
FWD
BACK
BACKFWD
6461-1
6461-3
6461-2
Item Description
1 A Port - Swing Right
2 B Port - Swing Left
3 T Port - Tank Port
4 P Port - Pressure Port
5 A Port - Telescope Out or Auxiliary Hoist Down
Item Description
6 Telescope In or Auxiliary Hoist Up
7 A Port - Lift Down
8 B Port - Lift Up
9 A Port - Main Hoist Down
10 B Port - Main Hoist Up
