Millenium HX RO System
3030226 Rev. D 4-3 Screen Operation And Specifications
4.1 Theory of Operation
The Millenium HX Portable Reverse Osmosis system (RO) is a fully cabinetized unit that
purifies a given feed water (by way of reverse osmosis) for use in hemodialysis
applications. The RO possesses monitoring for RO feed water pressure, RO feed water
quality, pump outlet pressure, product water pressure, product water temperature,
product water quality and membrane performance (percent rejection). The RO pump
provides the pressure required to push water through the RO membrane. The fluid
controls provide a means of managing flow rates and pressures. The following
paragraphs detail the function of these fluid control components, which are used within
the RO.
4.2 Fluid Components
The Millenium HX product water wetted components consist of the following materials.
Component
Material
Product Tubing
Nylon
RO Membrane Housing
304/316 SS
Plastic Fittings
Acetal or Polypropylene, Buna-N, 316 SS
O-rings/Gaskets
Viton
®
, & EPDM
Check Valve
316 Stainless Steel, Hastelloy, Viton
®
Manifold Blocks
Acetal
Product Hose
Silicone
End Caps
Polypropylene
Solenoid Valves
300 & 400 SS, Glass filled Nylon, Silicon,
316SS, Viton
®
, Polypropylene
Pressure Transducer
316/316L Stainless Steel
Conductivity Probe
PTFE, 316 Stainless Steel, ABS
Element
Polyamide, Polysulfone, Vinyl
