Models ESM303 & ESM303H Test Stands User’s Guide
14
After pressing menu, the initial Test Function Setup screen appears as follows:
Label
Description
ESC
Exits Test Function Setup, reverts to Operating Mode
< –
Scrolls to the previous function
– >
Scrolls to the next function
ENTR
Selects the function, allowing it to be modified
When the functions have been configured and are ready to be saved, press ESC to exit Test Function
Setup.
Note:
Changes can be made to an unlimited number of settings before saving.
If the PROFILES function is installed, the changes may be saved to the desired profile name. The screen
appears as follows:
Label
Description
ESC
Exits Test Function Setup, reverts to Operating Mode
+
Scrolls to the next saved profile
EDIT
Press to edit the profile name. The first character will be
flashing. Press + to change the character and –> to
advance to the next character.
SAVE
Saves the settings under the specified profile name
Refer to the Profiles sub-section for further details on selecting and deleting profiles.
If PROFILES is not installed, the screen appears as follows:
Make the appropriate selection.
4.1 Speed
If the Independent Speeds option has not been installed, both directional speeds will be the same, and is
programmed via the SPEED function. If the Independent Speeds option is installed, UP SPEED / RIGHT
SP and DN SPEED / LEFT SP functions will be present, and may be set individually.
Default setting: 10 in/min / 250 mm/min
Available settings: 0.02 – 45 in/min / 0.5 – 1,100 mm/min
S
P
E
E
D
:
2
0
.
0
0
E
S
C
<
−
−
>
E
N
T
R
S
A
V
E
A
S
:
E
X
A
M
P
L
E
1
E
S
C
+
E
D
I
T
S
A
V
E
S
A
V
E
C
H
A
N
G
E
S
?
N
O
Y
E
S
