1.2 Physical features
Note the following physical features. The user’s guide will reference this terminology.
1.2.1 ESM303
Base
Base plate
Lower grip
Upper grip
Force gauge
Column
Control panel
Emergency stop
Limit
switch
(upper)
Test sample
Crosshead
Interface
cable
Column cap
Limit
switch
(lower)
Control panel
mounting bracket
