Models ESM303 & ESM303H Test Stands User’s Guide
15
4.2 Auto return
With this function, the crosshead moves to a limit switch or soft limit (force set point, distance limit,
preload, or break), whichever occurs first, and stops. Then, the crosshead returns to the other limit and
stops. The test speed is dictated by the setting described in the previous section. The return speed is
locked to maximum speed. The maximum speed depends on whether or not the optional high speed
range has been installed.
Default setting: off
Available settings: off, on
Label
Description
+ or –
Cycles through the available settings
ENTR
Returns to the Test Function Setup menu
ESC
Exits the function without saving changes
Note:
If AUTO RETURN is turned on, CYCLING is automatically turned off and the KEYS function is
automatically set to MAINTAINED mode. See following pages for details on the CYCLING and KEYS
functions.
4.3.1 Cycling (CYCLES)
This setting allows the user to configure the number of up and down cycles through which the crosshead
will sequence. One cycle consists of the crosshead moving to a limit switch or soft limit, whichever occurs
first, at the specified speed, stopping for the specified amount of dwell time, and returning to the other
limit at the specified speed. If the Independent Speeds function is not enabled, the speed will be the same
in both directions.
Default setting: 00000 (off)
Available settings: 00000 – 99999
U
P
S
P
E
E
D
:
1
0
.
7
3
E
S
C
−
+
E
N
T
R
Label
Description
+
Increments the speed setting. Holding down + will
increment at an increasingly faster rate.
–
Decrements the speed setting. Holding down – will
decrement at an increasingly faster rate.
ENTR
Returns to the Test Function Setup menu
ESC
Exits the function without saving changes
A
U
T
O
R
E
T
U
R
N
o
f
f
E
S
C
−
+
E
N
T
R
C
Y
C
L
E
S
:
0
0
0
0
0
E
S
C
−
+
E
N
T
R
