Models ESM303 & ESM303H Test Stands User’s Guide
20
Default setting: 80%
Available settings: 1% - 95% (1% increments)
Label
Description
+ or –
Increases or decreases the value.
ENTR
Returns to the Test Function Setup menu
ESC
Exits the function without saving changes
Note:
When using an ESM303 / ESM303H test stand with a Series 7 instrument, enable Break Detection in
either the test stand or the instrument. The function will not work if simultaneously enabled in both
devices.
4.9 Control source (CONTROL)
This setting corresponds to the source of test stand control, as follows:
CONSOLE
The test stand is controlled either from the control panel or from MESURgauge Plus software
running on a PC.
PC
The test stand is controlled from a custom written PC application (not MESURgauge Plus). If any
functions are changed on the front panel, these settings will be ignored, except for Auto Return
or Cycling. If either of these functions is turned on, PC control will be turned off.
Default setting: CONSOLE
Available settings: CONSOLE, PC
Label
Description
+ or –
Cycles through the available settings
ENTR
Returns to the Function Setup menu
ESC
Exits the function without saving changes
4.10 Baud rate
This setting corresponds to the baud rate setting of the computer program controlling the test stand.
Default setting: 115200
Available settings: 1200, 2400, 4800, 9600, 19200, 38400, 57600, 115200
B
R
E
A
K
%
P
E
A
K
:
1
0
E
S
C
−
+
E
N
T
R
C
O
N
T
R
O
L
:
C
O
N
S
O
L
E
E
S
C
−
+
E
N
T
R
B
A
U
D
R
A
T
E
:
1
1
5
2
0
0
E
S
C
−
+
E
N
T
R
