Mark-10 ESM303 - Overview; List of Included Items

Models ESM303 & ESM303H Test Stands User’s Guide
3
1 OVERVIEW
1.1 List of included items
Description
Qty.
ESM303
Qty.
ESM303H
1
Force gauge mounting adapter
1
Indicator / load cell mounting adapter
4
Force gauge / indicator mounting screws,
#6-32 x 1/2
4
Indicator mounting screws, #6-32 x 1/2
2
Limit switch thumb screws, #6-32 x 5/8
2
Limit switch thumb screws, #6-32 x 5/8
1
Control panel
1
Control panel
1
Control panel mounting bracket
1
Control panel mounting bracket
-
-
1
Adapter, control panel bracket to frame
(shipped installed)
1
Screw for mounting control panel bracket
to column, 1/4-20 x 1”, with lock washers
2
Screws for mounting control panel bracket
to adapter, #8-32 x 1” (shipped installed)
-
-
2
Screws for mounting adapter to frame,
#10-32 x 1” (shipped installed)
2
Screws for mounting control panel to
bracket, 1/4-28 x 1-1/4”, with lock
washers
2
Screws for mounting control panel to
bracket, 1/4-28 x 1-1/4”, with lock
washers
1
Accessories kit:
- #10-32F small hook
- #10-32M medium hook
- #10-32F 2” diameter comp. plate
- #10-32 M/F 2” extension rod
- #10-32 F/F coupler
- Adapter, 5/16-18M to #10-32F
- Set screw, #10-32 x 3/4" (3)
- Hex nut, #10-32 (3)
- Allen wrench set
1
Accessories kit:
- #10-32F small hook
- #10-32M medium hook
- #10-32F 2” diameter comp. plate
- #10-32 M/F 2” extension rod
- #10-32 F/F coupler
- Adapter, 1/2-20M to #10-32F
- Adapter, 1/4-28M to 5/16-18F
- Adapter, 5/16-18M to #10-32F (2)
- Set screw, #10-32 x 3/4" (3)
- Hex nut, #10-32 (3)
- Allen wrench set
1
Resource CD
1
Resource CD
1
Power cord
1
Power cord
Additional optional items are available, such as an adjustable base plate, connection cables, and column
extensions. Instructions for installing a column extension and retrofitting the test stand with the travel
indication option are provided later on in this user’s guide.
