Mark-10 ESM303 - Technical Specifications

Models ESM303 & ESM303H Test Stands User’s Guide
42
13 SPECIFICATIONS
Load capacity:
< 24 in [610 mm]/min: 300 lbF [1.5 kN]
> 24 in [610 mm]/min: 200 lbF [1 kN]
Standard speed range:
0.5 – 13 in/min [13 – 330 mm/min]
Optional speed range:
0.02 – 45 in/min [0.5 – 1,100 mm/min]
Maximum travel:
18.0 in [457 mm]
Speed setting accuracy:
±0.2%
Speed variation with load:
±0% [Stepper motor driven]
Travel accuracy:
±0.002 in. per 10 in. [±0.05 mm per 250 mm]
Travel resolution:
0.001 in [0.02 mm]
Limit switch repeatability:
0.001 in [0.03 mm]
Power:
Universal input 80-240 VAC, 50/60 Hz, 60W
Fuse type:
1.2 A, 250V, 3AG, SLO BLO
Weight (without options):
ESM303: 56.5 lb (25.6 kg)
ESM303H: 62.5 lb (28.4 kg)
Environmental Conditions:
40 - 100°F [5 - 40°C], max. 93% humidity, non-condensing
14 DIMENSIONS
14.1 ESM303
