Masimo Rad-97 Operator's Manual

Rad-97 Chapter 6: Noninvasive Blood Pressure (NIBP)
www.masimo.com 112 Masimo
Blood Pressure Measurement
Spot Check NIBP Measurement
1. Ensure that the correct patient profile is selected before measurement.
WARNING: Only use Rad-97 in Neonatal mode with a neonatal blood pressure cuff
to measure blood pressure on neonates.
Note: The Patient Category determines the initial inflation pressure of NIBP.
Ensure that the proper patient profile and associated patient category are
appropriate for the intended patient.
2. To change the patient profile, touch the Main Menu icon , then select Profiles
.
Touch the Profile Name and select the desired patient profile.
3. Properly place the blood pressure cuff on patient. See Cuff Selection and
Placement on page 110.
4. Touch the Start button to begin measurement.
5. Wait for measurement to complete or touch the Stop button to stop measurement.
6. Wait for measurement values to appear to ensure that the NIBP measurement is
complete.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
