Masimo Rad-97 Operator's Manual

Rad-97 Chapter 10: Troubleshooting
www.masimo.com 140 Masimo
Troubleshooting Rad-97
The following section lists possible Rad-97 symptoms, potential causes, and next steps.
For more information, see Chapter 9: Alarms and Messages on page 123.
Symptom Potential Causes Next Steps
Device does not turn on
• Depleted Battery.
• Internal failure.
• Check AC Power
connection.
• Contact Masimo
Service. See
Contacting Masimo on
page 173.
System failure technical alarm
active
• Internal failure. • Turn Rad-97 Off and
On.
•
Contact Masimo
service. See
Contacting
Masimo on page 173.
Speaker does not work
• Device audible settings
may be incorrect.
• Internal failure.
• Turn Rad-97 Off and
On.
• Check that Alarms and
Sounds have not been
silenced.
• Check that Alarms and
Sounds volumes
settings.
• Check the device is not
in All Mute.
• Check that the device
speaker is not being
muffled.
•
Contact Masimo
service. See
Contacting
Masimo on page 173.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
