Masimo Rad-97 Operator's Manual

www.masimo.com 179 Masimo
Index
3
3D Alarms • 58, 59, 128
A
About • 57, 97
About Alarms • 48, 89, 124, 128
About Desat Index • 62, 128
About Parameter Information • 62, 64,
65, 66, 67, 68, 71, 74, 76, 77, 78, 81, 82,
83, 89, 97
About Pi Delta • 128, 129
About the Action Menu • 48, 51, 52, 114,
115
About the Main Screen • 43, 48
About the Status Bar • 26, 48, 49, 85, 87,
91, 92, 93, 96, 126
About the System Status Light • 38, 56
About This Manual • 7
AC Power Indicator • 50
Access Control • 40, 85, 86, 94, 103, 107
Accessing Main Menu Options • 48, 57,
106
Accuracy • 151
Accuracy (ARMS*) • 146
Acoustic Waveform View • 79
Acquisition System • 33
Adaptive Threshold Alarm (ATA) Feature
• 63, 127
Additional Settings • 57, 59, 78
Additional Settings for NIBP • 80, 84
Additional Settings for Pi • 65, 66
Additional Settings for PVi • 66, 67
Additional Settings for RRa • 67, 68, 69
Additional Settings for RRp • 67, 70, 71
Additional Settings for SpHb • 71, 73
Additional Settings for SpO2 • 62, 63, 90
Admitting a Patient • 118
Alarm Interface • 123
Alarm Limit Test • 169
Alarms • 153
Appendix
Concepts of Alarm Response Delay • 177
Attach NIBP Cuff • 42
Audio Pause • 49, 85, 96, 126
Automatic Interval Measurement • 52,
113
B
Back View • 37, 41, 100, 169
Battery Charge Status Indicator • 50, 51,
172
Battery Operation and Maintenance • 41,
172
Blood Pressure Measurement • 112
Bluetooth • 49, 86, 92, 121
Brightness • 86, 94, 141, 172
C
Calibration • 170
Calibration for NIBP • 80, 85
Capturing Screenshots • 100
Changing Profiles • 103
Chapter 1
Technology Overview • 23
Chapter 10
Troubleshooting • 123, 137, 168
Chapter 11
Specifications • 145
Chapter 12
Service and Maintenance • 85, 134, 135,
136, 167
Chapter 2
Description • 35
Chapter 3
Setting Up • 39
Chapter 4
Operation • 43

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
