Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 97 Masimo
About
For information about individual parameters, see About Parameter Information on page 78.
Use the About screen to view the serial number as well as Rad-97 software and hardware
version information. These details may be helpful during troubleshooting.
Option * Description
Serial Number Displays the serial number for the device.
MCU Displays the version number of the device board software.
Processor Displays the version number of the system level software.
MX Board Displays the version number of the technology level software.
* These fields are read-only and cannot be configured by the user.
Trends
Trend settings allow the user to configure the Y-axis maximum and Y-axis minimum for each
parameter. The maximum and minimum possible values differ depending on the selected
parameter. See Customizing Trend View on page 54 for additional information.
Trend Settings
Use the Trend Settings screen to configure Trend Views on the Main Screen and trend data
storage on Rad-97.
Option Description Factory Default
Settings
User Configurable Settings
Default
Duration
Sets the time duration
displayed in trend lines.
2 hours
15, 30, or 45 minutes
1, 2, 4, 8, 12, or 24 hours
Clear Trends Deletes all stored trend data. N/A
Press Clear to delete all
stored trend data.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
