Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 96 Masimo
Device Output
The Device Output screen allows the user to configure additional data output options. A Nurse
Call can be triggered based on alarm, low Signal IQ events, or both. In addition, Nurse Call
Polarity can be inverted to accommodate local Nurse Call station requirements.
The Device Output screen can also be accessed by selecting the Device Output icon on the
Status Bar. See About the Status Bar on page 49.
Option Description Factory
Default
Setting
Configurable
Settings
Nurse Call
Trigger
Controls the source of monitoring which
sets off the trigger.
Alarms
Alarms,
Alarms+SIQ, or
Low SIQ
Nurse Call
Polarity
Controls the mechanism of action for
triggering to occur. Should be changed to
accommodate institutional Nurse Call
settings.
Normal
Normal or
Inverted
USB Port*
Controls the communication protocol used
to transmit parameter data to a 3rd party
device or an EMR system.
IAP
None, IAP, ASCII
1, or IntelliBridge
IntelliBridge
Module
Identifies the type of IntelliBridge Module
connected to the USB Port.
Note: USB Port selection must be
Intellibridge for option to be available.
EC-10/B EC-10/B or A
* When IAP, ASCII 1, or IntelliBridge is selected, the Device Output icon displays in the Status
Bar. If None is selected, no Device Output icons display in the Status Bar. See About the
Status Bar on page 49.
Note: The Nurse Call feature is disabled when Audio Pause is enabled and Nurse Call Trigger
is set to Alarms. For more information about Audio Pause, see Audio Pause on page 126.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
