Masimo Rad-97 Operator's Manual

www.masimo.com 103 Masimo
Chapter 5: Profiles
The following chapter contains information about profiles and profile settings.
Profiles Overview
Note: When in Sleep Study mode or optional Home mode (when available), Profiles settings
are not available. The device operates in the profile set during Continuous Monitoring mode.
See Sleep Study on page 90 and Home on page 89.
Rad-97 contains a Profiles screen which lets the user customize settings for different patient
populations:
• Adult
Adult profile is the factory default profile. Displays in the Status bar as ADULT and
the color of the Profile button turns Blue.
• Pediatric
Displays in the Status bar as PEDIATRIC and the color of the Profile button turns
Green.
• Neonatal
Displays in the Status bar as NEO and the color of the Profile button turns Pink.
If the Profile setting is changed to NEO, Rad-97 will remain in the previously selected Profile
setting even after the device is powered off and on again.
Note: If no changes are made to the profile settings, Rad-97 automatically resets to the
default Adult profile after the device is powered off and on again.
The active profile displays in the Status Bar. In the following example, the Adult profile is
active.
To restore all Rad-97 settings to factory default settings, see Access Control on page 94.
Changing Profiles
Changing Profiles is done through the Profiles Settings screen. There are different ways to
access the Profiles Settings screen.
• Touch the Profiles shortcut in the Status Bar, as shown below.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
