Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 56 Masimo
About the System Status Light
The System Status Light provides visual indications of alarms and system messages. The
light will illuminate in different colors depending on the state of the device.
To locate the System Status Light, see Side and Top Views on page 38.
Light Status Alarm
Priority
Indication
None None System is off
Green None System is monitoring patient; no alarms.
Yellow Low
There is an active, low priority alarm.
Examples of low priority alarms:
• No cable is connected.
• Cable connected but there is no sensor connected to
cable.
• Sensor is off patient and has been acknowledged.
Flashing
Yellow
Medium
There is an active medium priority alarm.
Example of a medium priority alarm:
• Device battery is low.
Flashing Red High
There is an active high priority alarm.
Example of a high priority alarm:
• The sensor has come off of the patient.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
