Rad-97 Chapter 12: Service and Maintenance
www.masimo.com 172 Masimo
Neonates 150 ± 5mmHg
Test Method
The steps outlined below are for manually performing an overpressure test. Some or all of
these steps may be incorporated into a service tool provided by the medical device
manufacturer.
1. Set the corresponding patient profile. See Chapter 5: Profiles on page 103.
2. Perform an NiBP measurement.
3. Connect a manometer, volume and hand bulb to Module using "T" adapters.
4. From the Main Screen, touch the Start NIBP measurement button.
5. Touch the "Test" button on the display.
6. Increase the pressure to approximately 250mmHg using the hand bulb.
7. VERY SLOWLY increase the pressure from 280 to the overpressure point. Once it is
reached, the valves will open and the pressure will rapidly reduce to 0mmHg.
8. If one of the overpressure values is not within the pass criteria above, return the
module for service to an authorized service center.
Maintenance
Battery Operation and Maintenance
The Rad-97 includes a lithium ion rechargeable battery.
Before using the Rad-97 without the AC power connected, check the battery status indicator
and ensure that the battery is fully charged. See Battery Charge Status Indicator on page 51.
To charge the Rad-97 battery, refer to Initial Battery Charging on page 41.
Note: When battery run time is significantly reduced, it is advisable to completely discharge
and fully recharge the battery.
Run Time for Rad-97
The following table outlines the estimated minimum run time of the battery in the Rad-97.
• The time estimates are based on a fully charged battery.
• Time estimates are also based on specific operating modes.
For optimal battery run time, configure the device to automatically adjust the brightness. See
Brightness on page 94.
Configuration
Operating Mode Minimum run time (Est.)
Rad-97
• Not connected to AC power
• Wireless connected
• Bluetooth connected
• Brightness level set to maximum
2 hours
