Masimo Rad-97 Operator's Manual

www.masimo.com 121 Masimo
Chapter 8: Third-Party Devices
Flexible measurement expansion is possible through the Rad-97 Bluetooth connection.
Rad-97 can display parameters and measurements captured by third-party technologies in an
all-in-one view on Rad-97.
When a third-party device is connected, Rad-97 automatically creates a window that displays
all the data from that device on the Main Screen.
Connect Device to Rad-97
To connect a third-party device to Rad-97 using Bluetooth, perform the following:
1. Ensure Bluetooth is enabled on Rad-97. See Bluetooth on page 92.
2. Ensure Bluetooth is enabled on the third-party device; refer to the third-party
device's Operator's Manual if needed.
3. Rad-97 will automatically connect to the device.
4. The third-party device can now be used with Rad-97. Refer to the third-party
device's Operator's Manual for proper operation.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
