Masimo Rad-97 Operator's Manual

www.masimo.com 3 Masimo
Contents
About This Manual-------------------------------------------------------------------------------------------7
Product Description, Features and Indications for Use ----------------------------------------------- 9
Product Description ------------------------------------------------------------------------------------- 9
Indications for Use ------------------------------------------------------------------------------------- 10
Contraindications -------------------------------------------------------------------------------------- 11
Safety Information, Warnings and Cautions ---------------------------------------------------------- 13
Safety Warnings and Cautions ----------------------------------------------------------------------- 13
Performance Warnings and Cautions --------------------------------------------------------------- 15
Cleaning and Service Warnings and Cautions --------------------------------------------------- 20
Compliance Warnings and Cautions ---------------------------------------------------------------- 21
Chapter 1: Technology Overview ------------------------------------------------------------------------ 23
Signal Extraction Technology® (SET®) ------------------------------------------------------------ 23
rainbow Pulse CO-Oximetry Technology ----------------------------------------------------------- 26
rainbow Acoustic Monitoring™ (RAM™) ------------------------------------------------------------ 31
Chapter 2: Description ----------------------------------------------------------------------------------- 35
General System Description ------------------------------------------------------------------------- 35
Features ------------------------------------------------------------------------------------------------- 36
Chapter 3: Setting Up------------------------------------------------------------------------------------ 39
Unpacking and Inspection -------------------------------------------------------------------------- 39
Preparation for Use ----------------------------------------------------------------------------------- 39
Guidelines for Setting Up ---------------------------------------------------------------------------- 39
Powering the Rad-97 ON and OFF ------------------------------------------------------------------ 40
Initial Battery Charging ------------------------------------------------------------------------------- 41
Nurse Call Connection -------------------------------------------------------------------------------- 41
Attach NIBP Cuff --------------------------------------------------------------------------------------- 42
Masimo Kite --------------------------------------------------------------------------------------------- 42
Third-Party Devices ------------------------------------------------------------------------------------ 42
Chapter 4: Operation -------------------------------------------------------------------------------------- 43
Using the Touchscreen and Home Button --------------------------------------------------------- 43
About the Main Screen --------------------------------------------------------------------------------48
About the System Status Light --------------------------------------------------------------------- 56

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
