Masimo Rad-97 Operator's Manual

www.masimo.com 39 Masimo
Chapter 3: Setting Up
This chapter contains information about setting up Rad-97 before use.
Unpacking and Inspection
To unpack and inspect the Rad-97:
1. Remove the Rad-97 from the shipping carton and examine it for signs of shipping
damage.
2. Check all materials against the packing list. Save all packing materials, invoice
and bill of lading. These may be required to process a claim with the carrier.
3. If anything is missing or damaged, contact the Masimo Technical Service
Department. See Return Procedure on page 173.
Preparation for Use
Prior to setting up the Rad-97 for monitoring, perform the following steps:
1. Confirm that you have all system components:
• Rad-97 Device
• AC Power Cord
• Patient Cable
• Sensor
2. Read the Safety Information, Warnings and Cautions on page 13.
3. Setup the Rad-97 according to the directions provided in this Operator's Manual.
Guidelines for Setting Up
When setting up Rad-97, follow these guidelines:
1. Place on a stable, hard, flat, dry surface near the patient.
Caution: Do not place the Rad-97 where the controls can be changed by the
patient.
Note: If placed in a vertical position, rotate the swivel foot at the base of the
device as shown in Side and Top Views on page 38 for stability.
2. Maintain a minimum of three (3) centimeters (approximately one [1] inch) of free
space around Rad-97.
3. Ensure that the Speaker is not covered to avoid a muffled alarm sound.
4. Charge Rad-97's battery fully before use. See Initial Battery Charging on page 41.
5. Rad-97 should not be operated outside the environmental conditions listed in the
specifications section. See Environmental on page 152.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
