Masimo Rad-97 Operator's Manual

www.masimo.com 167 Masimo
Chapter 12: Service and Maintenance
The following chapter contains information about cleaning, battery operation, performance
verification, service, repair, and warranty.
Cleaning
The Rad-97 is a reusable device. The device is supplied and is intended to be used non-sterile.
WARNING: To avoid electric shock, always turn off the Rad-97 and physically disconnect the
AC power and all patient connections before cleaning.
CAUTION: To avoid permanent damage to the Rad-97, do not use undiluted bleach (5% -
5.25% sodium hypochlorite) or any other cleaning solution not recommended.
To surface clean the Rad-97:
• Wipe the outer surfaces using a dampened soft cloth with one of the
recommended cleaning solutions twice or until the surfaces are free of any visible
residue.
Note: Pay particular attention to cracks, crevices, and hard to reach areas of the device.
• Repeat the above cleaning step using a fresh wipe.
• Allow the Rad-97 to dry thoroughly before using again.
CAUTION: To avoid permanent damage to the Rad-97, do not use excessive amounts of
liquids to clean the device.
The surfaces of the Rad-97 may be cleaned with the following solution(s):
• 70% Isopropyl Alcohol
• Cidex Plus (3.4% glutaraldehyde)
• 10% (1:10) chlorine bleach to water solution
• Quaternary ammonium chloride solution wipe
Nurse Call Setting Connections
For maximum flexibility, either normally open or normally closed signals are available. During
an alarm condition or a low Signal IQ event, depending on the configuration of the device
output, the normally open pin will be connected to the common pin and the normally closed
pin will be disconnected. In addition, the Nurse Call Polarity can be inverted to accommodate
various nurse call station requirements.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
