Masimo Rad-97 Operator's Manual

www.masimo.com 117 Masimo
Chapter 7: Admit to and Discharge from
Patient SafetyNet
The Admit/Discharge icon is located in the bottom left of the screen and allows clinicians to
admit or discharge patient's on Masimo Patient SafetyNet directly from Rad-97.
Icon Description
Admit - Select to admit a patient.
Discharge - Indicates a patient is currently admitted. Select to discharge admitted
patient.
Note: In order to use this feature, Masimo Patient SafetyNet software V5.0.6.5 or higher is
required.
Not Admitted
A Not Admitted message will appear on the Rad-97 screen when the sensor is placed onto a
patient and a patient has not yet been admitted on Rad-97. Press the Admit button on the
screen to admit the patient or press Skip and the patient data will not be transmitted to
Patient Safety Net.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
