Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 92 Masimo
Wi-Fi
The Wi-Fi radio allows for networked communication of data and alarm signals between
Rad-97 and a secondary patient monitoring station, Masimo Patient SafetyNet, over an IEEE
802.11 a/b/g wireless network.
Rad-97 uses only configured MAC addresses to establish wireless communications to prevent
unauthorized connections to other wireless devices. As risk mitigation, in the event of the
loss of wireless communication, Rad-97 alarm capabilities are designed to be independent of
Wi-Fi communication in order to ensure alarms are received.
Use the Wi-Fi screen to enable or disable Wi-Fi connectivity. When Rad-97 is connected to a
Wi-Fi network, the Wi-Fi icon on the Status Bar indicates the strength of the connection. The
user can also access the Wi-Fi screen by pressing the Wi-Fi icon on the Status Bar. See About
the Status Bar on page 49.
Option Description Factory Default
Settings
User Configurable
Settings
Wi-Fi
Enables or disables Wi-Fi
connectivity.
Off On or Off
Additional fields in the Wi-Fi screen display read-only settings about the Wi-Fi connection
that cannot be configured by the user.
Your Masimo sales representative can provide necessary information regarding an initial
Wi-Fi connection.
Bluetooth
Use the Bluetooth screen to enable or disable Bluetooth connectivity. When Bluetooth
connectivity is enabled, the Bluetooth icon will appear in the Status Bar. The user can also
access the Bluetooth screen by pressing the Bluetooth icon on the Status Bar. See About the
Status Bar on page 49.
Option Description Factory
Default
Settings
User
Configurable
Settings
Bluetooth
Enables or disables Bluetooth
connectivity.
Off On or Off

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
