Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 91 Masimo
Screen Orientation
Use Screen Orientation to set screen preferences.
From the Screen Orientation screen, change any of the following options:
Options Description Factory Default
Settings
User Configurable
Settings
Auto
Orientation
Allows the device to
automatically adjust screen
content depending on device
orientation.
On Off or On
Orientation When Auto Orientation is Off,
allows the user to manually set
screen orientation.
Portrait (with
device in vertical
position)
Landscape (with
device in
horizontal
position)
Portrait, Inverted
Portrait, Landscape, or
Inverted Landscape
Ethernet
Use the Ethernet screen to enable or disable Ethernet connectivity. When Ethernet
connectivity is enabled, the Ethernet icon will appear in the Status Bar. The user can also
access the Ethernet screen by pressing the Ethernet icon on the Status Bar. See About the
Status Bar on page 49.
Option Description Factory Default
Settings
User Configurable
Settings
Ethernet
Enables or disables Ethernet
connectivity.
On On or Off
Additional fields in the Ethernet screen display read-only settings about the Ethernet
connectivity that cannot be configured by the user.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
