Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 89 Masimo
Home
When optional Home mode is available, Rad-97 operates using the Continuous Monitoring
settings in effect at the time Home mode is enabled (Profiles, Alarms, Trends, etc.). Rad-97
operation changes as follows when in Home mode:
• Alarm tone volume is set to the highest level and cannot be changed.
• Pulse tone volume can be changed; however, all other sound settings are disabled.
• The Alarm Silence button is not included on the Main Screen. See About Alarms on
page 124.
• Profile settings are not available (device operates in the profile set during
Continuous Monitoring mode).
• When parameters in the Main Menu are selected, only parameter information is
displayed. Settings are not displayed or available. See About Parameter
Information on page 78.
• Profiles, Device Settings, and Trend Settings are not displayed in the Main Menu.
Change Settings/Exit Home Mode
To change settings or switch to a different device mode, select the Rad-97 menu from the
Main Menu.
1. When the screen displays, press the key.
2. Enter the following: 6 2 7 4
To undo an entry, press the Backspace key.
3. Press the Enter key. The Main Menu screen will display.
• From the Main Menu, make changes to Rad-97 settings as necessary and
select the back button to return to Home mode operation.
• From the Main Menu, select Device Settings > Device Mode to change
operating modes.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
