Masimo Rad-97 Operator's Manual

Rad-97 Chapter 4: Operation
www.masimo.com 78 Masimo
About Parameter Information
Additional information about each parameter is available.
To access additional information about parameters:
1. From the Parameter Settings screen, touch the About icon. The following is an
example for SpO
2
.
2. An About screen appears for the selected parameter and displays information
about the parameter.
Additional Settings
Use the Additional Settings screen to configure the following:
Option Description Factory
Default
Settings
User Configurable Settings
Sensitivity
Mode
Change Sensitivity
Mode.
See Sensitivity
Modes Overview on
page 52.
APOD MAX, APOD, NORM
Waveform
Mode
Change the
Waveform View.
See Waveform Mode
on page 79.
Pleth + Sig IQ
+ Acoustic
Acoustic, Pleth + Sig IQ, Pleth + Sig IQ
+ Acoustic, PVi Pleth + Sig IQ, or PVi
Pleth + Sig IQ + Acoustic
SmartTone Enable or disable the
SmartTone.
See Sounds on page
85.
Off On, Off

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
