Masimo Rad-97 Operator's Manual

Rad-97 Chapter 10: Troubleshooting
www.masimo.com 141 Masimo
Symptom Potential Causes Next Steps
Device screen is blank
• The device is Off.
• The brightness display
is not correct.
• Battery may be
depleted.
• Internal failure.
• Turn Rad-97 Off and
On.
• Adjust the brightness
setting. See Brightness
on page 94.
• Check AC power
connection.
• Contact Masimo
service. See Contacting
Masimo on page 173.
Touchscreen/Buttons do not
respond when pressed
• EMI (Electro Magnetic
Interference).
• Internal failure.
• Check device AC power
is properly grounded.
• Relocate the device
from other devices that
may cause
electromagnetic
interference.
• Contact Masimo
service. See Contacting
Masimo on page 173.
Battery run time significantly
reduced
• Battery not fully
charged.
• Battery damaged.
• Battery capacity
effected.
• Check battery charge
level indicator.
• Check battery is fully
charged.
• Contact Masimo
service. See Contacting
Masimo on page 173.
Device does not detect that
patient cable is connected
• Cable connector not
properly connected to
the device.
• Damaged connector.
• Damaged cable.
• Cable expired.
• Internal failure.
• Remove and reconnect
cable.
• Ensure the connector is
fully connected to the
device.
• Replace cable.
• Contact Masimo
service. See Contacting
Masimo on page 173.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
