Masimo Rad-97 Operator's Manual

Rad-97 Chapter 10: Troubleshooting
www.masimo.com 142 Masimo
Symptom Potential Causes Next Steps
Device does not detect that the
sensor is connected
• Sensor not properly
connected to device.
• Improper placement of
sensor.
• Damaged sensor.
• Sensor expired.
• Internal failure.
• Remove and reconnect
sensor.
•
Ensure the connector is
fully connected to the
device.
• Reapply sensor to the
patient. Refer to sensor
Directions For Use.
• Replace sensor.
• Turn Rad-97 Off and
On.
•
Contact Masimo
service. See
Contacting
Masimo on page 173.
Nurse Call does not work
• Nurse call connector
not properly connected
to the device.
• Nurse call port not
configured correctly.
• Nurse call system not
available.
• Internal failure.
• Check Nurse call
connector is fully
connected to the
device.
• Check Nurse call port
configuration. See
Device Output on page
96.
• Check Nurse call
system availability.
•
Contact Masimo
service. See
Contacting
Masimo on page 173.
Device does not communicate
to other external devices
through wired connection
• External device is not
compatible.
• Device port settings
are not configured
correctly.
• Communication cable
is not properly
connected.
• Connected network is
not available.
• Internal failure.
• Check external device
compatibility.
• Check device data port
settings. See Device
Output on page 96.
• Check communication
cable connection.
• Check connected
network settings and
availability.
•
Contact Masimo
service. See
Contacting
Masimo on page 173.

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
