Masimo Rad-97 Operator's Manual

Rad-97 Chapter 11: Specifications
www.masimo.com 149 Masimo
The below Bland-Altman plot represents the correlation of the (SpO
2
+ SaO
2
)/2 versus (SpO
2
-
SaO
2
) under no motion with an upper 95% and lower 95% limits of agreement.
Figure 1: Disposable (RD SET Series) Sensors (ARMS 70-100%)
Resolution
Parameter Resolution
SpO
2
1%
PR 1 BPM
RRa 1 RPM*
SpHb 0.1 g/dL
0.1 mmol/L
1 g/L
SpCO 1%

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
