Masimo Rad-97 Operator's Manual

Rad-97 Chapter 11: Specifications
www.masimo.com 156 Masimo
Communication (Wi-Fi)
Available Data Rates
802.11a - 6, 9, 12, 18, 24, 36, 48, 54 Mbps.
802.11b - 1, 2, 5.5, 11 Mbps.
802.11g - 6, 9, 12, 18, 24, 36, 48, 54 Mbps.
Communication (Bluetooth)
Type Bluetooth
Frequency 2402-2480 MHz
Max Peak Output Power Bluetooth 1.3 dBm
Classification of Output Power Rating Conducted
Output Power Type Fixed at the Factory
Modulation Types DH5
Modulation Signals Analog and Digital
Available Data Rates Bluetooth 1 Mbps
Security and Authentication
Encryption 64/128-bit WEP, Dynamic WEP, WPA-TKIP, WPA2-AES
Authentication
Open System, Shared Key, Pre-Shared Key (PSK), 802.1X: LEAP, PEAP< TTLS,
TLS, EAP-FAST

Masimo Rad-97 Specifications

General

Display Size	7 inches
SpO2 Accuracy	±2% (70-100%)
Pulse Rate Accuracy	±3 bpm
Perfusion Index Range	0.02% to 20%
Pleth Variability Index Range	0% to 100%
SpO2 Range	0% to 100%
SpHb Range	0 to 25 g/dL
SpCO Range	0% to 40%
Battery Type	Rechargeable lithium-ion
Operating Temperature	5°C to 40°C (41°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity Range	10% to 95% non-condensing
Display	Color touchscreen
Connectivity	Wi-Fi, Ethernet, Bluetooth
Power Supply	100–240 VAC, 50–60 Hz
Battery Life	Approximately 4 hours
Measurements	SpO2, Pulse Rate, Perfusion Index, Pleth Variability Index, SpHb, SpOC, SpMet, SpCO
Pulse Rate Range	25 to 240 bpm
HbCO Range	0-99%
MetHb Range	0-99%
SpMet Range	0-99%
Data Storage	Internal memory
Alarms	Audible and visual alarms for all parameters
