10 Matrox Extio 3 Series – User Guide
Hardware required (sold separately)
Depending on your device and setup, you may need the following hardware:
 CAT5e, CAT6, or CAT7 cable
 LC-LC fiber optic cable
 Multi-mode (62.5/125 µm (OM1), 50/125 µm (OM2, OM3, or OM4))
 Single-mode (9/125 µm (OS1 or OS2))
 Shielded DisplayPort™ 1.1 or 1.2 cable
*
Optional hardware (sold separately)
You may also need any of the following hardware:
 Multi-mode fiber optic transceiver
†
 Single-mode fiber optic transceiver
†
 Mini DisplayPort to DisplayPort adapter
‡
 Analog audio cable
 Matrox secure cable solution
Networked-
Internet / WAN
with Site-to-
Site VPN mode
Log into your receiver and switch to
different transmitters. For more
information, see “Setting up
networked mode (LAN or Internet /
WAN with Site-to-Site VPN)”, page
61.
Remotely manage, monitor, and
configure your networked Extio 3
devices. For more information, see
“Installing Matrox Extio Central
Manager software”, page 62.
Networked-
Internet with
IPSec VPN
mode
Log into your receiver and switch to
different transmitters. For more
information, see “Setting up
networked mode (Internet with
IPSec VPN)”, page 74.
Remotely manage, monitor, and
configure your networked Extio 3
devices. For more information, see
“Installing Matrox Extio Central
Manager software”, page 75.
* The On-Screen Display (OSD) is available only on the receiver.
* Shielded DisplayPort™ 1.2 cable is required for 4K60 resolutions.
† To purchase a multi-mode fiber optic transceiver (part number XTO3-SFPMM) or single-mode fiber optic transceiver (part
number XTO3-SFPSM) for your Matrox product, contact your Matrox representative.
‡ Not recommended for 4K60 resolutions.
