64 Matrox Extio 3 Series – User Guide
Change the keyboard shortcut through Extio Central Manager. For more information, see your
Matrox Extio Central Manager User Guide.
Enabling Networked-LAN or Networked-Internet / WAN with Site-to-Site
VPN mode
To use your devices in Networked-LAN or Networked-Internet / WAN with Site-to-Site VPN mode,
click the
Enable LAN
or
Enable Internet / WAN with Site-to-Site VPN
button from the OSD startup
screen, in the
Networked
section under
Select your operation mode
. Wait for the mode to be enabled.
For more information, see “Basic functions”, page 64. To use Networked mode, you need a user name
and password. To obtain a user name and device password (or if you’ve forgotten your user name or
device password), contact your Extio 3 administrator.
Using the OSD (On-Screen Display)
If your devices are networked, the OSD enables you to log into your receiver and switch to different
transmitters.
Basic functions
Note:
To change the operation mode of your Extio 3 configuration (for example, changing
from Point-to-Point mode to Networked-LAN or Networked-Internet / WAN with Site-to-
Site VPN mode), you need to perform a configuration reset of your devices. For more
information, see “Changing the operation mode of your devices”, page 85.
Logout Click this to log out of the device.
Search Search for a system by device serial number, friendly name,
IP address, or name of the user connected.
Wake-on-LAN Click this to wake up your transmitter if it turns off. This has
no effect if a transmitter isn’t detected.
Rescan network Click this to discover devices outside of the receiver’s subnet
or unicast network.
Disconnect Click this to disconnect from a transmitter.
Connect Click this to connect to a new transmitter.
Close Click this to close the OSD.
