Matrox Extio 3 Series – User Guide 93
Maximum distance (Point-to-Point mode)
*
External power supply
†
Extio N3408/N3208
transmitter card
Extio N3408/N3208
transmitter unit
Extio N3408/N3408
receiver unit
OM2, OM3, OM4 (50/125µm)
multi-mode cable type
550 meters (1804 feet)
OM1 (62.5/125µm) multi-mode
cable type
275 meters (902 feet)
OS1, OS2 (9/125µm) single-mode
cable type
5 kilometers (3.10 miles)
CAT5e, CAT6 100 meters (328 feet)
* Longer distances are supported in networked mode over LAN and Internet / WAN with Site-to-Site VPN. Over Internet / WAN
with Site-to-Site VPN, network conditions vary according to region. For an optimal user experience, we recommend a ping
time of less than 20ms and +/- 10% worst case jitter. For more information, contact your Matrox representative.
Extio N3408/N3208
transmitter unit
Extio N3408/N3208
receiver unit
Input a.c. voltage range 100V to 240V a.c.
Input frequency 50 to 60 Hz
Input connector IEC 60320-C14
Output voltage 12V d.c.
Output current 5A
Output connector DIN 4-pin male with lock
Maximum power 60W
† Only use the power supply originally supplied by Matrox with your Matrox Extio 3 Series product.
