92 Matrox Extio 3 Series – User Guide
Extio 3 receiver unit
Product dimensions
Extio N3408 receiver unit Extio N3208 receiver unit
Product type
Standalone appliance Standalone appliance
Form factor 1 RU, half width 1 RU, half width
Video output connectors
4× DisplayPort
(with stereo L-PCM audio)
2× DisplayPort
(with stereo L-PCM audio)
Audio input connector (analog) 4× mini-stereo jacks 4× mini-stereo jacks
Audio output connector 1× mini-stereo jack 1× mini-stereo jack
Microphone input 1× mini-stereo jack 1× mini-stereo jack
RS232 connector 1× DE9 (or DB9) – Male 1× DE9 (or DB9) – Male
Networking interface 1000 Base-T Ethernet 1000 Base-T Ethernet
USB ports 6× USB 2.0 (front) 4× USB 2.0 (front)
DisplayPort version 1.1 
DisplayPort version 1.2 
*
* DisplayPort version 1.2 is supported on connector labeled 4 only.
—
Color space
YUV 4:4:4
RGB 8:8:8
YUV 4:4:4
RGB 8:8:8
Maximum output resolution
†
† Additional display resolutions may be available. For more information, contact your Matrox representative.
4× 1920 × 1080 @60 Hz,
3× 1920 × 1200 @60 Hz,
2× 2560 × 1600 @60 Hz,
2× 3840 × 2160 @30 Hz,
1× 3840 × 2160 @60 Hz
2× 1920 × 1200 @60 Hz,
1× 2560 × 1600 @60 Hz
Power connector DIN 4-pin female DIN 4-pin female
Power consumption 57W (typical 41W) 35W (typical 27W)
Laser emissions
‡
‡ Only when using a multi-mode SFP module.
850 µm laser compliant to 21CFR, Subpart J, Class 1
Regulatory compliance
Class A: CE, FCC, ICES-3, KC, RCM, VCCI
CSA
Extio N3408/N3208
transmitter unit
Extio N3408/N3408
receiver unit
Length
18.9 cm (7.45 inches)
4.26 cm (1.676 inches)
21.66 cm (8.526 inches)
Height
Width/Depth
