26 Matrox Extio 3 Series – User Guide
When a stream connection is active,
Congestion control
level can be set from the OSD
Receiver
tab
Connection
tab.
Note
: If the transmitter setting is currently set to Off, the
Congestion control
option is disabled.
When connected to an aggregated layout, you will have individual control over
MTU
and
Congestion
control
of all transmitters in the aggregated layout.
File structure and syntax for Swanctl.json
See “Appendix E - File structure for swanctl.json”, page 108.
File structure for the VPN configuration file (strongswan.zip)
The following is the file structure that should be used for creating the
Strongswan.zip
file:
strongswan.zip/
strongswan.zip/swanctl.json --> Mandatory, describes swanctl.conf
strongswan.zip/triplets.dat --> Optional, copied to /etc/ipsec.d/triplets.dat
strongswan.zip/x509/ --> Optional, copied recursively to /etc/swanctl/x509
strongswan.zip/x509ca/ --> Optional, copied recursively to /etc/swanctl/x509ca
strongswan.zip/x509aa/ --> Optional, copied recursively to /etc/swanctl/x509aa
strongswan.zip/x509ac/ --> Optional, copied recursively to /etc/swanctl/x509ac
strongswan.zip/x509crl/ --> Optional, copied recursively to /etc/swanctl/x509crl
strongswan.zip/x509ocsp/ --> Optional, copied recursively to /etc/swanctl/x509ocsp
strongswan.zip/private/ --> Optional, copied recursively to /etc/swanctl/private
strongswan.zip/pubkey/ --> Optional, copied recursively to /etc/swanctl/pubkeys
strongswan.zip/pkcs12/ --> Optional, copied recursively to /etc/swanctl/pkcs12
The zip file can also have the following structure:
strongswan.zip/<folder>/swanctl.json
strongswan.zip/<folder>/...
Note
: The
Network
tab in the ECM is not enabled while in the VPN mode. You will be able
to read the information shown but not modify it.
