Matrox Extio 3 Series – User Guide 81
VPN tab
VPN connect and VPN disconnect
Connect to the IPSec VPN using the VPN connect button at the bottom, or if you are already
connected, use the
VPN disconnect button to disconnect.
Aggregator mode in Networked-Internet with IPSec VPN
With aggregator mode, your Extio 3 receiver unit can gather video streams from multiple Extio 3
transmitter units into a single layout. The user operations in aggregator mode are similar whether the
user is connected in Networked-LAN, Networked-Internet / WAN with Site-to-Site VPN, or
Networked-Internet with IPSec VPN mode. For more information, see “Aggregator mode”, page 68.
Details View the Configuration , Connection , and IP address details here.
Configuration - Import file
from USB
Import the Strongswan.zip VPN configuration file.
Configuration -
Authentication
A secret can be an authentication credential, or a private key
decryption passphrase.
 Type – The secret Type can be “eap”, “xauth”, “ntlm”, “ike”,
“ppk”, “private”, or “pkcs12”.
 Loaded – Secrets can be loaded from the configuration file,
or they can be dynamically loaded by the user.
 Persistent – When a checkbox is present under Persistent ,
it means that the secret doesn’t have to be re-loaded at
every VPN connection.
