Matrox Extio 3 Series - Accessing the OSD (On-Screen Display)

Matrox Extio 3 Series – User Guide 63
Obtaining Matrox Extio Central Manager software
To obtain the latest Extio Central Manager software, contact your Matrox representative. Matrox
makes the latest Extio Central Manager software available on the Matrox web site
(www.matrox.com/extio3/software
).
Installing Matrox Extio Central Manager software
To install the software for your Extio 3 product, run the installation program for your software
package on any system on the network. Follow the on-screen instructions.
Accessing Extio Central Manager software
Windows 11/10/7 – To access the main interface of Extio Central Manager software:
 Windows 11 and Windows 10 – Click Start  All apps *  Matrox Extio Central
Manager
*  Matrox Extio Central Manager . (* Depending on your configuration of
Windows, this part may not be necessary.)
 Windows 7 – Click Start  All Programs (or Programs )  Matrox Extio Central
Manager
*  Matrox Extio Central Manager . (* Depending on your version and
configuration of Windows, this part may not be necessary.)
Configuring Extio Central Manager software
Before you can access and use the OSD, your Extio Central Manager software must be configured. For
information on how to use and configure Extio Central Manager software, see the Matrox Extio
Central Manager User Guide.
Accessing the OSD (On-Screen Display)
The OSD is available only with Extio 3 receiver devices. To access the OSD, enter the OSD keyboard
shortcut on the keyboard connected to your receiver. The default keyboard shortcut is the [Scroll
Lock] key.
Changing the OSD keyboard shortcut
You can change the keyboard shortcut used to access the OSD.
Note: Only one (1) instance of Extio Central Manager software needs to be installed.
Note: To access the OSD, make sure you obtain a user name and password from your
Extio 3 administrator. For more information, contact your network administrator.
