Matrox Extio 3 Series - Extio N3408 Transmitter or Receiver Unit

34 Matrox Extio 3 Series – User Guide
Extio N3408 transmitter or receiver unit
Extio N3408 transmitter unit (Front)
Extio N3408 transmitter unit (Back)
Note: For more information on connecting a redundant network, see “Setting up link
redundancy”, page 41.
Video Out
(DisplayPort 1.1)
USB 2.0
RS232
SFP
DisplayPort 1.1 DisplayPort 1.1
2
1
1 2
Host Connections
12V
5A
DisplayPort 1.1 DisplayPort 1.2
3
4
RS232Line In
12V d.c. 5A
power
LAN1
(RJ45)
Video In
(DisplayPort 1.1)
Line Out
LAN2
(LC-LC)
USB 2.0
Video In
(DisplayPort 1.2)
LAN2
(RJ45)
